A “roller-bearing”, “clevis hanger” or “band hanger” pipe support, used to support roof-mounted gas pipes, HVAC piping, electrical conduit, solar piping and other mechanical piping. Unique design allows thermal expansion and contraction of pipes thus preventing damage to the roof membrane. Pipes rest on a polycarbonate or steel roller, clevis hanger or band hanger.
The deck base is 16″x 18″ and has a maximum cradle width of 6″.
Max Pipe Size:
5″ OD maximum recommended pipe capacity or 6″ OD maximum with insulation.
Max Pipe Clearance:
Adjustable height up to 18″.
Max Load Weight:
Maximum load weight may not exceed 250 lbs. per pipestand. Even load required.
Manufacturer’s recommended spacing is not to exceed 10 foot centers depending upon the load. Make certain each pipestand is properly elevated to even load weight at all pipestands.
